Hotspot
IX20 User Guide
379
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network >Bridges> hotspot_bridge > Devices.
4. Click the to add a new device.
5. By default, For Device, select the appropriate Ethernet port.
By default, the ETH1 device is configured as the device for the ETH1 interface, and ETH2
configured as device in the LAN bridge, which isused by the ETH2 interface. As a result, when
you add an Ethernet port to the hotspot, you may need to reconfigure the Ethernet port
configuration for other interfaces. For example, to remove the port from the LAN bridge:
