Digi IX20 User Manual

Routing IProuting
IX20 User Guide
440
b. Configure the Ethernet WANinterface:
i. Click Network >Interfaces> ETH1.
ii. For Zone, select EthernetWAN.
5. Configure the policy-based route for traffic from the client device that will be sent over the
cellular WAN:
a. Click Network >Routes> Policy-based routing.
b. Click the  to add a new route policy.
c. For Label, type VoIP phone.
d. For Interface, select Modem.
e. Configure the source as the MACaddressof the VoIPphone:
i. Click to expand Source address.
ii. For Type, select MACaddress.
iii. For MACaddress, type 26:88:0E:23:50:C2.
f. Configure the destination zone:
i. Click to expand Destination address.
ii. For Type, select Zone.
iii. For Zone, select CellularWAN.

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
