Routing Virtual Router Redundancy Protocol (VRRP)
IX20 User Guide
468
3. Click Network >VRRP.
4. For Add VRRP instance, type a name for the VRRP instance and click .
The new VRRPinstance configuration is displayed.
5. Click Enable.
6. For Interface, select Interface: ETH2.
7. For Router ID, leave at the default setting of 50.
8. For Priority, leaveat the default setting of 100.
9. Click to expand Virtual IP addresses.
10. Click to add a virtual IPaddress.
11. For Virtual IP, type 192.168.3.3.
Task 2: Configure VRRP+ on device one
1. Click to expand VRRP+.
2. Click Enable.
3. Click to expand Monitor interfaces.
