Digi IX20 User Manual

Virtual PrivateNetworks(VPN) IPsec
IX20 User Guide
541
The Configuration window is displayed.
3. Click Network >SCEP Client.
4. For Add clients, enter a name for the SCEPclient and click .
The new SCEPclient configuration is displayed.
5. Click Enable to enable the SCEPclient.
6. For Renewable Time, type the number of daysthat the certificate enrollment can berenewed,
prior to the request expiring. This value must match the setting of the Allow renewal x days
before the certified is expired option on the Fortinet server.
7. (Optional) Click Debug to enable verbose logging in /var/log/scep_client.
8. Click to expand SCEP server.
9. For FQDN, type the fully qualified domain name or IPaddress of the Fortinet server.

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
