Virtual PrivateNetworks(VPN) Generic Routing Encapsulation (GRE)

IX20 User Guide

606

6. Save the configuration and apply the change

(config vpn ipsec tunnel ipsec_endpoint2)> save

Configuration saved.

Task three: Create a GRE tunnel

 Web

1. Click VPN >IP Tunnels.

2. For Add IP Tunnel, typegre_tunnel2 and click .

3. For Local endpoint, select the IPsec endpoint interface created in Task two (Interface: ipsec_

endpoint2).

4. For Remote endpoint, type the IPaddressof the GREtunnel on IX20-1, 172.30.0.1.

5. Click Apply to savethe configuration and apply the change.

 Command line

1. At the command line, type config to enter configuration mode:

> config

(config)>

2. Add a GREtunnel named gre_tunnel2:

(config)> add vpn iptunnel gre_tunnel2

(config vpn iptunnel gre_tunnel2)>

3. Set the local endpoint to the IPsec endpoint interface created in Task two

(/network/interface/ipsec_endpoint2):

(config vpn iptunnel gre_tunnel2)> local /network/interface/ipsec_

endpoint2

(config vpn iptunnel gre_tunnel2)>
