Virtual PrivateNetworks(VPN) Generic Routing Encapsulation (GRE)
IX20 User Guide
607
4. Set the remote endpoint to the IPaddress of the GREtunnel on IX20-1, 172.30.0.1:
(config vpn iptunnel gre_tunnel2)> remote 172.30.0.1
(config vpn iptunnel gre_tunnel2)>
5. Save the configuration and apply the change
(config vpn iptunnel gre_tunnel2)> save
Configuration saved.
>
Task four: Create an interface for the GREtunnel device
Web
1. Click Network >Interfaces.
2. For Add Interface, type gre_interface2 and click .
3. For Zone, select Internal.
4. For Device, select the GREtunnel created in Task three (IP tunnel: gre_tunnel2).
5. Click to expand IPv4.
6. For Address, type 172.31.0.2/30 for a virtual IPaddresson the GREtunnel.
7. Click Apply to savethe configuration and apply the change.
