Digi IX20 User Manual

Firewall ConfigureQuality of Serviceoptions
IX20 User Guide
963
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Enable one of the preconfiged bindings:
n
To enable the Outbound binding:
(config)> firewall qos 0 enable true
(config)>
n
To enable the Inbound binding:
(config)> firewall qos 1 enable true
(config)>
4. Set the interface for the binding. Use the index number of the binding; for example, to set the
interface for the Outbound binding:
a. Use the ?to determine available interfaces:
(config)> firewall qos 0 interface ?
Interface: The network interface.
Format:
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/eth1
/network/interface/eth2
/network/interface/loopback
Current value:
(config)> firewall qos 0 interface
b. Set the interface. For example:
(config)> firewall qos 0 interface /network/interface/eth1
(config)>
5. Examine the remaining default settingsand modify as appropriate for your network.
6. Save the configuration and apply the change
(config)> save
Configuration saved.
>

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
