Viewing VLANs
7-2 802.1Q VLAN Configuration
IftheD‐SeriesdeviceistobeconfiguredformultipleVLANs,itmaybedesirabletoconfigurea
management‐onlyVLAN.ThisallowsastationconnectedtothemanagementVLANtomanage
thedevice.Italsomakesmanagementsecurebypreventingconfigurationviaportsassignedto
otherVLANs.
Tocreate
asecuremanagementVLAN,youmust:
ThecommandsusedtocreateasecuremanagementVLANarelistedinTable 7‐29.Thisexample
assumesthemanagementstationisattachedto
ge.1.1andwantsuntaggedframes.
Theprocessdescribedherewouldberepeatedoneverydevicethatisconnectedinthenetworkto
ensurethateachdevicehasasecuremanagementVLAN.
Viewing VLANs
Purpose
TodisplayalistofVLANscurrentlyconfiguredonthedevice,todeterminehowoneormore
VLANswerecreated,theportsallowedanddisallowedtotransmittrafficbelongingtoVLAN(s),
andifthoseportswilltransmitthetrafficwithaVLANtagincluded.
Step Task Refer to page...
1. Create a new VLAN. 7-4
2. Set the PVID for the desired switch port to the VLAN created in Step 1. 7-8
3. Add the desired switch port to the egress list for the VLAN created in
Step 1.
7-14
4. Assign host status to the VLAN. 7-17
5. Set a private community name and access policy. 5-14
Table 7-29 Command Set for Creating a Secure Management VLAN
To do this... Use these commands...
Create a new VLAN and confirm settings. set vlan create 2 (“set vlan” on page 7-4)
(Optional) show vlan 2 (“show vlan” on page 7-3)
Set the PVID to the new VLAN. set port vlan ge.1.1 2 (“set port vlan” on page 7-8)
Add the port to the new VLAN’s egress list. set vlan egress 2 ge.1.1 untagged (“set vlan egress” on
page 7-14)
Remove the port from the default VLAN’s
egress list.
clear vlan egress 1 ge.1.1 (“clear vlan egress” on
page 7-14)
Assign host status to the VLAN. set host vlan 2 (“set host vlan” on page 7-17)
Set a private community name and access
policy and confirm settings.
set snmp community private (“set snmp community” on
page 5-14)
(Optional) show snmp community (“show snmp
community” on page 5-13)
