Enterasys D2 D2G124-12P User Manual

set port vlan
7-8 802.1Q VLAN Configuration
set port vlan
UsethiscommandtoconfigurethePVID(portVLANidentifier)foroneormoreports.
Syntax
set port vlan port-string pvid [modify-egress | no-modify-egress]
Parameters
Defaults
None.
Mode
Switchcommand,read‐write.
Usage
ThePVIDisusedtoclassifyuntaggedframesastheyingressintoagivenport.
Example
Thisexampleshowshowtoaddge.1.10totheportVLANlistofVLAN4(PVID4).
D2(su)->set vlan create 4
D2(su)->set port vlan ge.1.10 4 modify-egress
clear port vlan
Usethiscommandtoresetaport’s802.1QportVLANID(PVID)tothehostVLANID1.
Syntax
clear port vlan port-string
Parameters
port‐string Specifiestheport(s)forwhichtoconfigureaVLANidentifier.Foradetailed
descriptionofpossibleport‐stringvalues,referto“PortStringSyntaxUsed
intheCLI”onpage 4‐1.
pvid SpecifiestheVLANIDoftheVLANtowhichport(s)willbeadded.
modify‐egress (Optional)Addsport(s)
toVLANʹsuntaggedegresslistandremovesthem
fromotheruntaggedegresslists.
no‐modify‐egress (Optional)Doesnotpromptforormakeegresslistchanges.
Note: The following command will reset the specified port’s egress status to tagged. To set the
specified ports back to the default egress status of untagged, you must issue the set port vlan
command as described on page 7-8.
port‐string Specifiestheport(s)toberesettothehostVLANID1.Foradetailed
descriptionofpossibleport‐stringvalues,referto“PortStringSyntaxUsed
intheCLI”onpage 4‐1.
