set diffserv class rename

8-8 Differentiated Services Configuration

Youcannotcreateandaddaclasstoapolicybeforeaddinganyrules(matchconditions)tothe

class.Onceaclassisaddedtoapolicy,youcannotaddanymorerules(matchconditions)tothe

class.Youcannotcreateoutboundpolicies.

Youcanonlyaddrulesthatfitinto

thesamecategory(showninthegroupingsabove)toaclass.

Forexample,ifyoucreateaclassandaddthematchconditionsdstipanddstl4port,youwillonly

beabletoaddotherrulesfromtheL3group.

Classmatchesoflayer4destinationorsourcemustbesequenced

beforethecorresponding

protocolmatch,asillustratedinthethirdexamplebelow.

Youcanonlyaddclassesofthesamecategorytoapolicy.

Examples

Thisexampleshowshowtomatchthe“admin”classtosourceIPaddress130.10.0.32andonly

thatIPaddresstype:

D2(rw)->set diffserv class match srcip admin 130.10.0.32 255.255.255.255

Thisexampleshowshowtomatchthe“admin”classtoVLAN10:

D2(rw)->set diffserv class match vlan admin 10

ThisexampleshowshowtomatchtheʺhttpʺclasstoTCPpacketswithadestinationportof80

(HTTP).Thelayer4portmatchmustprecedetheprotocoltype.

D2(rw)->set diffserv class match dstl4port keyword http http

D2(rw)->set diffserv class match protocol keyword http tcp

set diffserv class rename

UsethiscommandtochangethenameofaDiffservclass.

Syntax

set diffserv class rename classname newclassname

Parameters

Defaults

None.

Mode

Switchcommand,Read‐Write.

Example

ThisexampleshowshowtorenametheDiffserv“admin”classto“system”:

D2(rw)->set diffserv class rename admin system

Note: The match type every will work with any group.

classname SpecifiestheclassnamepreviouslysetforthisnewDiffservclass.

newclassname Specifiesanewclassname.

Enterasys D2 D2G124-12P User Manual
