Configuring Policy Class of Service (CoS)
9-16 Policy Classification Configuration
enabled,thedefaultanduser‐assignedpolicy‐basedsettingswilloverrideport‐basedsettings
describedinChapter 10.
About Policy-Based CoS Configurations
Onceenabledusingthesetcosstatecommandasdescribedin“setcosstate”onpage 9‐18,you
canaddtothepolicy‐basedCoSfunctionbydefiningnewportgroupings,andassigninginbound
ratelimiters.Theprocessforuser‐definedCoSconfigurationinvolvesthefollowingstepsand
associatedcommands
listedinProcedure 9‐2.Anexamplefollowstheprocedure.
Example
Thisexamplecreatesdifferentinboundratelimitersfortwoportgroupsandthenassignsthemto
trafficwithaCoSsettingof0.
1. Configuretwoportgroups,oneforuserportsandoneforuplinkportsandassignportstothe
groups.Portgroup1.0willrepresentuserports,group2.0
willrepresentuplinkports.
D2(su)->set cos port-config irl 1.0 name Users ports ge.1.1-46
D2(su)->set cos port-config irl 2.0 name Uplink ports ge.1.47-48
D2(su)->show cos port-config
Inbound Rate Limiting Port Configuration Entries
----------------------------------------------------------------------
Port Group Name :Default
Port Group :0
Port Type :0
Assigned Ports :none
----------------------------------------------------------------------
Port Group Name :Users
Port Group :1
Port Type :0
Assigned Ports :ge.1.1-46
----------------------------------------------------------------------
Port Group Name :Uplink
Port Group :2
Port Type :0
Assigned Ports :ge.1.47-48
----------------------------------------------------------------------
2. Configurephysicalinboundratelimitersforeachportgroup.Fortheuserportgroup(1.0),
createanIRL(irl‐indexof1)for512kbps.Fortheuplinkportgroup(2.0),createanIRL(irl‐
indexof1)for10megabitspersecond(10,000kbps).
D2(su)->set cos port-resource irl 1.0 1 unit kbps rate 512
D2(su)->set cos port-resource irl 2.0 1 unit kbps rate 10000
Procedure 9-2 User-Defined CoS Configuration
Step Task Command(s)
1. Enable CoS set cos state
2. Create CoS port groups set cos port-config
3. Define physical rate limiters for groups set cos port-resource
4. Create virtual reference for the IRL resource
(physical reference) for each port group
set cos reference
5. Add IRL reference to CoS settings table set cos settings
