Filter Group Commands
D-Series CLI Reference 13-15
Defaults
None.
Mode
Switchcommand,read‐write.
Example
ThisexampleshowshowtoclearRMONevent1:
D2(rw)->clear rmon event 1
Filter Group Commands
Thepacketcaptureandfilterfunctionisdisabledbydefault.Onlyoneinterfacecanbeconfigured
forcapturingandfilteringatatime.
Whenpacketcaptureisenabledonaninterface,theD‐Seriesswitchwillcapture100framesas
closetosequentiallyaspossible.These100frameswillbeplaced
intoabufferforinspection.If
thereisdatainthebufferwhenthefunctionisstarted,thebufferwillbeoverwritten.Once100
frameshavebeencaptured,thecapturewillstop.Filteringwillbeperformedontheframes
capturedinthebuffer.Therefore,onlyasubset oftheframes
capturedwillbeavailablefor
display.
Onechannelatatimecanbesupported,withuptothreefilters.Configuredchannel,filter,and
buffercontrolinformationwillbesavedacrossresets,butcapturedframeswithinthebufferwill
notbesaved.
Thisfunctioncannotbeusedconcurrentlywithportmirroring.Thesystem
willchecktoprevent
concurrentlyenablingbothfunctions,andawarningwillbegeneratedintheCLIifattempted.
Commands
Note: Packet capture is sampling only and does not guarantee receipt of back to back packets.
For information about... Refer to page...
show rmon channel 13-16
set rmon channel 13-16
clear rmon channel 13-17
show rmon filter 13-17
set rmon filter 13-18
clear rmon filter 13-19
