144
Search scope
User DN search scope, including:
• all-level—All subdirectories.
• single-level—Next lower level of subdirectories under the base
DN.
User searching parameters User search parameters.
User object class
User object class for user DN search. If no user object class is
configured, this field displays
Not configured
.
Username attribute User account attribute for login.
Username format Format for the username sent to the server.
Attribute map
LDAP attribute map used by the scheme. If no LDAP attribute map is
used, this field displays
Not configured
.
ip
Use ip to configure the IP address and port number of the LDAP server.
Use undo ip to restore the default.
Syntax
ip ip-address [ port port-number ] [ vpn-instance vpn-instance-name ]
undo ip
Default
An LDAP server does not have an IP address or port number.
Views
LDAP server view
Predefined user roles
network-admin
Parameters
ip-address: Specifies the IP address of the LDAP server.
port port-number: Specifies the TCP port number of the LDAP server. The value range for the
port-number argument is 1 to 65535, and the default value is 389.
vpn-instance vpn-instance-name: Specifies an MPLS L3VPN instance to which the LDAP server
belongs. The vpn-instance-name argument is a case-sensitive string of 1 to 31 characters. If the
server is on the public network, do not specify this option.
Usage guidelines
The LDAP service port configured on the device must be consistent with the service port of the LDAP
server.
If you change the IP address and port number of the LDAP server, the change is effective only on the
LDAP authentication that occurs after the change.
Examples
# Specify the IP address and port number as 192.168.0.10 and 4300 for LDAP server ccc.
<Sysname> system-view
[Sysname] ldap server ccc
[Sysname-ldap-server-ccc] ip 192.168.0.10 port 4300
