H3C MSR Series Command Reference

1147
Field
Description
Expiration time Period of time in which the mapping entry will expire.
Type
Mapping entry type:
• static—The entry is statically configured.
• cached—The entry is dynamically obtained.
• Incomplete—The entry is dynamic and
incomplete.
Flags
Mapping entry flags:
• unique—The mapping entry in the registration
request cannot be overwritten by a mapping entry
that has the same protocol address and different
public addresses. A client can register the new
entry with the server only after the mapping entry
on the server expires.
• used—This mapping entry is used for packet
forwarding.
• up—Packets can be forwarded.
• ipsec—IPsec negotiation succeeded. Packets will
be protected by IPsec.
• init—Initialization state.
display nhrp statistics
Use display nhrp statistics to display NHRP packet statistics for a tunnel interface.
Syntax
display nhrp statistics [ interface tunnel interface-number ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
interface tunnel interface-number: Specifies an mGRE tunnel interface by its number in the range
of 0 to 4095. If you do not specify this option, the command displays NHRP packet statistics for all
tunnel interfaces.
Examples
# Display NHRP packet statistics.
<Sysname> display nhrp statistics
Tunnel0:
NHRP packets sent : 815
Resolution requests : 15
Resolution replies : 1
Registration requests : 0
Registration replies : 797
Purge requests : 2
Purge replies : 0
Error indications : 0
