H3C MSR Series Command Reference

248
<Sysname> display portal auth-error-record ip 192.168.0.188
User MAC : 0016-ecb7-a879
Interface : WLAN-BSS1/0/1
User IP address : 192.168.0.188
AP : ap1
SSID : byod
Auth error time : 2016-03-04 16:49:07
Auth error reason : The maximum number of users already reached.
# Display portal authentication error records for the portal user whose IPv6 address is 2000::2.
<Sysname> display portal auth-error-record ipv6 2000::2
User MAC : 0016-ecb7-a879
Interface : WLAN-BSS1/0/1
User IP address : 2000::2
AP : ap1
SSID : byod
Auth error time : 2016-03-04 16:49:07
Auth error reason : The maximum number of users already reached.
# Display portal authentication error records with the error time in the range of 2016/3/4 14:20 to
2016/3/4 14:23.
<Sysname> display portal auth-error-record start-time 2016/3/4 14:20 end-time 2016/3/4
14:23
User MAC : 0016-ecb7-a879
Interface : WLAN-BSS1/0/1
User IP address : 192.168.0.188
AP : ap1
SSID : byod
Auth error time : 2016-03-04 14:22:25
Auth error reason : The maximum number of users already reached.
Table 21 Command output
Field
Description
Total authentication error
records
Total number of portal authentication error records.
User MAC MAC address of the portal user.
Interface Access interface of the portal user.
User IP address IP address of the portal user.
AP AP name.
SSID Service set identifier.
Auth error time
Time when the portal user encountered an authentication error, in the
format of YYYY-MM-DD hh:mm:ss.
