H3C MSR Series Command Reference

360
Field
Description
NAS_subslot Subslot number of the BRAS, in the range of 0 to 31.
NAS_Port Port number of the BRAS, in the range of 0 to 63.
XPI.XCI
For ATM interfaces:
• XPI is VPI in the range of 0 to 255.
• XCI is VCI in the range of 0 to 65535.
For Ethernet interfaces or Ethernet trunk interfaces:
• XPI is PVLAN in the range of 0 to 4095. This field is
set to 4096 if there is no PVLAN.
• XCI is CVLAN in the range of 0 to 4095. This field is
set to 4096 if the user is not assigned to a VLAN as in
the situation where the end user device is directly
connected to a BRAS port.
For the access node to report its access line information to the BRAS, all fields will be set to 0s
except for the XPI and XCI fields.
• The access-node-id string specifies the attributes the of BRAS. Its format is
AccessNodeIdentifier/ANI_rack/ANI_frame/ANI_slot/ANI_subslot/ANI_port:ANI_XPI.ANI_XCI,
in which the :ANI_XPI.ANI_XCI portion is optional.
AccessNodeIdentifier
Identifier description of the access node, a string not
longer than 50 characters without spaces.
ANI_rack Rack number of the access node, in the range of 0 to 15.
ANI_frame Frame number of the access node, in the range of 0 to 31.
ANI_slot Slot number of the access node, in the range of 0 to 127.
ANI_subslot
Subslot number of the access node, in the range of 0 to
31.
ANI_port Port number of the access node, in the range of 0 to 255.
ANI_XPI.ANI_XCI
Optional.
This field is mainly used to carry CPE-side service
information, identifying the further service type
requirement. For example, use this field to identify specific
services in a multi-PVC scenario.
For ATM interfaces:
• ANI_XPI is VPI in the range of 0 to 255.
• ANI_XCI is VCI in the range of 0 to 65535.
For Ethernet interfaces or Ethernet trunk interfaces:
• ANI_XPI is PVLAN in the range of 0 to 4095. This
field is set to 4096 if there is no PVLAN.
• ANI_XCI is CVLAN in the range of 0 to 4095. This
field is set to 4096 if the user is not assigned to a
VLAN as in the situation where the end user device
is directly connected to a BRAS port.
If the device does not have rack, frame, or subslot information, 0 is padded in the corresponding
field.
For ATM interfaces, all fields in the access-node-id string are filled with 0s except for the
ANI_XPI and ANI_XCI fields.
• Examples of format 1:
