H3C MSR Series Command Reference

746
Predefined user roles
network-admin
network-operator
Parameters
brief: Displays brief SSL VPN gateway information. If you do not specify this keyword, the command
displays detailed SSL VPN gateway information.
name gateway-name: Specifies an SSL VPN context by its name. An SSL VPN context name is a
case-insensitive string of 1 to 31 characters, and can contain only letters, digits, and underscores (_).
If you do not specify an SSL VPN context, this command displays information about all SSL VPN
gateways.
Examples
# Display detailed information about all SSL VPN gateways.
<Sysname> display sslvpn gateway
Gateway name: gw1
Operation state: Up
IP: 192.168.10.75 port: 443
HTTP redirect port: 80
SSL server policy configured: ssl1
SSL server policy in use: ssl
Front VPN instance: vpn1
Gateway name: gw2
Operation state: Down
Down reason: Administratively down
IP: 0.0.0.0 Port: 443
SSL server policy configured: ssl1
SSL server policy in use: ssl
Front VPN instance： Not configured
Gateway name: gw3
Operation state: Up
IPv6: 3000::2 Port: 443
SSL server policy configured: ssl1
SSL server policy in use: ssl
Front VPN instance: Not configured
Table 110 Command output
Field
Description
Gateway name Name of the SSL VPN gateway.
Operation state
Operation status of the SSL VPN gateway:
• Up—The gateway is running.
• Down—The gateway is not running.

H3C MSR Series Specifications

General

Category	Network Router
IPv6 Support	Yes
Dimensions	Varies by model
Weight	Varies by model
Product Type	Modular Router
Ports	Varies by model
WAN Interfaces	Varies by model
Firewall	Yes
QoS	Yes
Wireless Support	Varies by model
USB Ports	Varies by model
Console Port	Yes
Power Supply	Varies by model
Redundancy	Varies by model
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% non-condensing
Series	MSR
Certifications	CE, FCC, RoHS
