HEADER ATTAC HMENT/D ETACH ME NT
WARNING
Keep hands clear of the area between guards and
knife at all times.
Figure 4.119: Cutterbar Hazard
20. Remove bol
t (A) at both sides of opening to allow
attachmen
t of adapter deck.
21. Rotate la
tch (B) forward and down to engage transition
pantube(
C).
Figure 4.120: AdapterLatch
22. Rotate
latch(A)downwitha15/16in. wrenchon
hex (B)
to raise feed deck so that bolt (C) can be
reins
talled to loc k th e latch position.
23. Repea
t for other side of feed draper deck.
Figure 4.121: Adapter Latch
147695 248 Revision A
