NEC Univerge SV9100 - Page 1083

1083
Program
Number
Program Name/Description
Input Data
Default
15-05-50
IP Telephone Terminal Basic Data Setup –
Peer to Peer Mode
On a per station basis enable or disable Peer to
Peer mode.
If disabled, non-MCU mode resource settings
are used in Programs 84-27-20 and 84-27-21.
0 = Disable
1 = Enable
1
84-19-65
SIP Extension CODEC Information Basic
Setup – Video Quality Mode
Specifies the SIP station video quality mode
when Peer to Peer is disabled in Program
15-05-50.
Mode 1 = CIF (352x288)
Mode 2 = VGA (640x480)
Used with Programs 84-27-20 for Mode 1 and
84-27-21 for Mode 2 video quality settings.
0 = Mode 1
1 = Mode 2
0
84-27-20
IPL Basic Setup – Maximum non-MCU Video
Channel Mode 1
Sets the number of VoIP DSP resources to
reserve for non-MCU mode 1 video. This
program is used if Peer to Peer is disabled for
standard SIP phones.
VoIP DSP resources are shared between video
and voice calls. The system will always keep 64
resources for voice calls. When changing this
program if resources are exceeded the system
will provide an error message and will not allow
the setting to be changed.
When changing this program, all DSP
resources are reset when idle. In progress calls are
not affected, but until all DSP resources go idle this
change will not take affect.
0 ~ 8
0
84-27-21
IPL Basic Setup – Maximum non-MCU Video
Channel Mode 2
Sets the number of VoIP DSP resources to
reserve for non-MCU mode 2 video. This
program is used if Peer to Peer is disabled for
standard SIP phones.
VoIP DSP resources are shared between video
and voice calls. The system will always keep 64
resources for voice calls. When changing this
program if resources are exceeded the system
will provide an error message and will not allow
the setting to be changed.
When changing this program, all DSP
resources are reset when idle. In progress calls are
not affected, but until all DSP resources go idle this
change will not take affect.
0 ~ 6
0
Operation
None
