698
IP Multiline Station (SIP) with NAPT:
GCD-CP10 Network Setup – IP Address
Assign the IP Address for the CPU NIC card.
When an GPZ-IPLE card is installed in the
system, it is recommended to set this Program
to 0.0.0.0.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
GCD-CP10 Network Setup – Default
Gateway
Assign the default gateway IP address for the
GCD-CP10.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0. 1 ~ 223.255.255.254
GCD-CP10 Network Setup – NAPT Router IP
Address (Default Gateway [WAN])
Assign the WAN address of the router that the
CCPU is using for NAT.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
GCD-CP10 Network Setup – IP Address
Set IP address for GPZ-IPLE.
The IP Address assigned in Program 10-12-01
cannot start with the same leading digits as the IP
Address assigned here.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
GCD-CP10 Network Setup – Subnet Mask
Set the subnet mask of the GPZ-IPLE.
128.0.0.0 | 192.0.0.0 | 224.0.0.0
|240.0.0.0 | 248.0.0.0 | 252.0.0.0
|254.0.0.0 | 255.0.0.0
|255.128.0.0 | 255.192.0.0
|255.224.0.0 | 255.240.0.0
|255.248.0.0 | 255.252.0.0
|255.254.0.0 | 255.255.0.0
|255.255.128.0 | 255.255.192.0
|255.255.224.0 | 255.255.240.0
|255.255.248.0 | 255.255.252.0
|255.255.254.0 | 255.255.255.0
|255.255.255.128
|255.255.255.192
|255.255.255.224
|255.255.255.240
|255.255.255.248
|255.255.255.252
|255.255.255.254
|255.255.255.255
DT800/DT700 Server Information Setup –
Register Mode
Assign the port number in which the SIP
messages are sent on the GPZ-IPLE. This
same port number must be assigned in the SIP
multiline terminals. If this command is changed,
it requires a CPU reset.
DT800/DT700 Server Information Setup –
Subscribe Session Port
Assign the port number to be used for
subscription messages between the SV9100
and the DT700 terminals.
