NEC Univerge SV9100 - ISDN - BRI Installation

799
Guide to Feature Programming
ISDN – BRI Installation:
Program
Number
Program Name/Description
Input Data
Default
10-03-01
ETU Setup (BRIA PKG) – ISDN Line Mode
Set up and confirm the Basic Configuration
data for each GCD-2BRIA. Use this program to
select the ISDN Line Mode.
0 = Not Used
1 = T-Point
1
10-03-03
ETU Setup (BRIA PKG Setup) – Connection
Type
Set up and confirm the Basic Configuration
data for each GCD-2BRIA. Confirm the
connection type for each GCD-2BRIA.
0 = Point-to-Multipoint
1 = Point-to-Point
0
10-03-04
ETU Setup (BRIA PKG Setup) – Layer 3
Timer Type
Set up and confirm the Basic Configuration
data for each GCD-PRTA. This program selects
the Layer 3 timer type (1 ~ 5). Each timer value
of Layer 3 is set up for each type in Program
81-06 (T-Bus).
1 ~ 5
1
10-03-08
ETU Setup (BRIA PKG Setup) – Dial Sending
Mode
Select ISDN protocol.
0 = Enblock Sending
1 = Overlap Sending
1
10-03-09
ETU Setup (BRIA PKG Setup) – Dial
Information Element
Select ISDN Protocol if Overlap Sending is
selected in Program 10-03-08.
0 = Keypad Facility
1 = Called Party Number
0
10-03-13
ETU Setup (PRTA PKG Setup) – Loss of
Signal Detection Limit
If the transmit/receive voltage is less than the
setting in Program 10-03-13, the system
considers this as Loss-Of-Signal and the PRI
does not come up. Note that there are different
values based on the setting in Program
10-03-12 for the PRI.
0 = Level 0
(lowest sensitivity)
1 = Level 1
2 = Level 2
3 = Level 3
4 = Level 4
5 = Level 5
6 = Level 6
7 = Level 7
(highest sensitivity)
2
10-06-01
ISDN BRI Setup – TEI Selection
Select the method the system uses when
assigning Terminal Endpoint Identifier (TEI)
values to the BRI Circuit.
0 = Select by SPID number
1 = Select by Channel ID
Number
0
10-06-02
ISDN BRI Setup – DID Mode
Select the method the system uses when
assigning DID Mode to the BRI Circuit.
0 = Route by Called Party
Number
1 = Route by Redirecting
Number
0
Program
Number
Program Name/Description
Input Data
Default
10-06-03
ISDN BRI Setup – SPID 1
Assign the SPID Number for B-Channel 1.
Dial (Maximum of 20 digits).
No Setting
10-06-04
ISDN BRI Setup – SPID 2
Assign the SPID Number for B-Channel 2.
Dial (Maximum of 20 digits).
No Setting
