NEC Univerge SV9100 - Encryption; SV9100 Terminals

1175
SV9100 Terminals
Description
The SV9100 is a full-featured IP based communications system providing a rich feature set with pure
Voice over IP (VoIP) communications, across corporate Local and Wide Area Networks (LAN and WAN).
The DT700/DT800 series telephones provide a converged infrastructure at the desktop, with a 10Base-
T/100Base-TX connection to the LAN and built-in hub for a PC connection to the telephone itself. The
system can provide peer to peer connections between the DT700/DT800 series telephones with voice
compression, offering existing IP telephone features with an enhanced user interface. On the WAN side,
the system can provide peer to peer connections over IP networks with the voice compression.
The SV9100 can provide legacy line/trunk interfaces to support the existing Time Division Multiplexing
(TDM) based infrastructure, such as analog telephones, digital telephones (DT300/DT400 series),
analog networks and digital networks (T1/E1, ISDN, etc.).
Encryption
This feature is supported with main software V 2.5 or above and terminal firmware 92.2.1.0 or above.
SV9100 supports AES 128 bit encryption. Program 10-46-08 Mode1 (read only) represents AES 128 bit.
DT700 Supported Encryption
Source
Destination
SRTP
Comment
DT700
DtermIP
S
DT700 VoIPDB
Encrypt between DT700 and VoIPDB
DT700
STD SIP (P2P)
N
DT700
STD SIP (Non P2P)
S
DT700 VoIPDB
Encrypt between DT700 and VoIPDB
DT700
DT700
S
DT700
PSTN
S
DT700 VoIPDB
Encrypt between DT700 and VoIPDB
DT700
IP Network
(SIP/H323/CCIS
S
DT700 VoIPDB
Encrypt between DT700 and VoIPDB
DT700
Encryption On
DT700
Encryption Off
N
S = Supported
N = Not Supported
