NEC Univerge SV9100 - SIP Extension Basic Information Setup

736
Program
Number
Program Name/Description
Input Data
Default
84-19-49
SIP Extension IP CODEC Information Basic
Setup – RTP Filter
To avoid incorrect voice pass connection, this
Program checks the sending side address from
received RTP packet at VoIPDB.
0 = Disable
1 = Enable
2 = Enable (include SSRC)
0
84-33-01
SIP Extension IP CODEC Information Basic
Setup – FAX Relay Mode
Enable/Disable the FAX relay mode.
0 = Disable
1 = Enable
2 = Each Port Mode
0
84-33-02
SIP Extension IP CODEC Information Basic
Setup – T.38 Protocol Mode
Sets the T.38 protocol mode.
1 = U/R
2 = RTP
3 = UDPTL
1
84-33-06
SIP Extension IP CODEC Information Basic
Setup – FAX Maximum Rate
Sets the maximum FAX rate.
0 = V.27ter, 4800bps
1 = V.29, 9600bps
2 = V.17, 14400bps
2
84-33-10
SIP Extension IP CODEC Information Basic
Setup – TCF Handling Method
Sets the training confirmation handling mode,
local denotes that the VoIP DB will generate
tone and check, Network denotes that TCF is
sent over the network provider.
0 = Receive TCF signal by
VoIPDB
1 = Through TCF signal to
external FAX
1
84-33-18
SIP Extension IP CODEC Information Basic
Setup – T.38 RTP Format Payload Number
Sets the payload number for T.38 RTP Format.
0, 2, 8, 96 ~ 127
103
84-34-01
VoIPDB DTMF Setup – DTFMF Relay Mode
Define the DTMF Relay Mode for Type 4 SIP
Extension.
0 = Disable
1 = RFC2833
2 = H.245
0
84-34-02
VoIPDB DTMF Setup – DTMF Payload
Number
Set DTMF Payload for standard SIP
extensions.
96 ~ 127
110
SIP Extension Basic Information Setup:
Program
Number
Program Name/Description
Input Data
Default
84-20-01
SIP Extension Basic Information Setup –
Registrar/Proxy Port
Define SIP station Proxy Port.
1 ~ 65535
5070
84-20-02
SIP Extension Basic Information Setup –
Session Timer Value
Define the periodic refresh time that allows both
user agents and proxies to determine if the SIP
session is still active.
1 ~ 65535
180
