Programming Flowchart of ISDN-PRI – Placing Calls
In 20-06-01, assign
Class of Service to extensions.
In 20-13-31, enter
0 to disable trunk
ID display by telco.
In 20-13-31, enter
1 to enable trunk
ID display by telco.
In 10-03-03, enter
'0'.
In 10-03-03, enter
'1'.
In 10-03-04, select the Layer 3 timer type (1-5). The timer value is
set up in Program 81-06 (T-Bus).
In 10-03-08, enter
'0'.
In 10-03-09, select either
Keypad Facility (0) or
Called Party Number (1) for
the dial information element.
20-08-02, enter ‘1’ to
enable outgoing
calls.
In 20-08-13, enter 0 to
disable calling number
display by telco.
In 20-08-13, enter 1 to
enable calling number
display by telco.
Start
In 10-03-01, determine the mode of the GCD-PRTA
(0=not set, 1=T-Bus).
No
Is the CRC
Multi-Frame
(CRC4)
used?
Yes
In 10-03-06, determine the length of cable used to connect from the CSU to
the
GCD-PRTA
(0=0-40m, 1=40-81m, 2=81-122m, 3=122-162m, 4=162-200m).
Enblock
Is the Dial
Sending Mode
Enblock or
Overlap
Sending?
In 10-03-08, enter
Overlap
'1'.
In 20-08-02, enter 0 to
disable outgoing calls.
No
Should system users be able to place
outgoing calls on trunks?
Yes
Stop
No
Should telco display the
calling number for outgoing
calls?
Yes
No
Should telco display the
trunk identification for
outgoing calls the extension
places?
Yes
Go To
A
