NEC Univerge SV9100 - Maximum System Capacities for Station Interface Blades

1288
The available interface blades and maximum capacities for Universal Slots with the
UNIVERGE SV9100 system are shown in Maximum System Capacities for Station
Interface Blades, Maximum System Capacities for Trunk Interface Blades and
Maximum System Capacities for Application Interface Blades.
Maximum System Capacities for Station Interface Blades
Station Interface Units
Description
Maximum Capacities
Basic Port Expanded Port
Package Package
Notes
GCD-8DLCA
This 8-port Digital Line Blade contains
eight circuits. Each circuit can support
any Attendant Console, multiline
terminal, or Single Line Telephone
adapter.
This blade is installed in slots 2~6 of a
chassis with CPU and slots 1~6 of
expansion chassis. The maximum
number depends on other station blades
installed. This blade shares the total
number of extension ports in the system.
No more than 80 DLC ports are
supported in a single chassis.
5
23
Note: 1
GCD-16DLCA
These blades are 16-port. Each circuit
can support any Attendant Console,
multiline terminal, or Single Line
Telephone adapter.
This blade is installed in slots 2~6 of a
chassis with CPU and slots 1~6 of
expansion chassis. The maximum
number depends on other station blades
installed. This blade shares the total
number of extension ports in the system.
No more than 80 ESI ports are supported
in a single chassis.
5
23
Note: 1
