NEC Univerge SV9100 - Page 830

830
required to capture packet data from the SV9100 IPLE Ethernet port.
Default Settings
Enabled
System Availability
Terminals
None
Required Component(s)
GCD-CP10 with GPZ-IPLE Daughter Board
System Version R1 License (0411)
System Port License (0300)
VoIP Resource License (5103)
K-CCIS over IP License (5012)
Related Features
Guide to Feature Programming
Program
Number
Program Name/Description
Input Data
Default
15-05-50
IP Telephone Terminal Basic Data Setup –
Peer to Peer Mode
On a per station basis enable or disable Peer to
Peer mode.
0 = Disable
1 = Enable
1
50-15-04
CCIS over IP Basic Information Setting –
Connection Method for Terminal
Choose the connection method for the DT700.
0 = Peer to Peer disable
1 = Peer to Peer enable
1
84-34-01
VoIPDB DTMF Setup – DTMF Relay Mode
When connecting to an SV8300/9300 or
SV8500/9300 option 05 (CCIS over IP) must be
set to 2 (H.245).
0 = Disable
1 = RFC2833
2 = H.245
0
