Ricoh MP CW2201 Service Manual

6. Select the target location and resolution, and then touch [Start Printing].
Target Location (Paper Source)
Paper Bypass Location Bypass paper feed
Paper Input Location 1 Roll Unit 1
Paper Input Location 2 Roll Unit 2
Print Quality
Speed Priority Draft (pattern A - G)
Stan. / Speed Priority (Drawg.) Standard quality (pattern A - J)
Quality Priority High quality (pattern A - J)
7. Check the test pattern.
To determine the adjustment value:
• Identify the number of the column where the square is faintest, or select the square where the
internal lines overlap to form a solid color.
Main Machine Installation
143

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
