1. Clean the sensor with a blower brush.
Precaution
To attach the sub-scan encoder sensor, catch the sub-scan encoder sheet by the sensor cutout [A].
Vertical Encoder Wheel, Timing Belt
The edge of the encoder wheel [A] is marked with coded patterns that are read by the encoder sensor
[B].
4. Replacement and Adjustment
