Ricoh MP CW2201 Service Manual

Installing the Scanner Stand
• Be sure to attach one lock washer to each hex socket bolt before you fasten the bolt.
1. Position the left and right supports of the scanner stand as shown below.
2. Set the two center stays between the left and right supports.
3. Make sure that the pattern of clustered cutouts [A] are down.
2. Installation
76
