Black Print Head Unit Accessories

No. Item Q'ty

1 Black Print Head Unit 1

2 Ink Collector Tank 1

3 Ink Cartridge (Black: K) 1

4 Protective Sheet 1

5 Plug (Uncapped) 2

6 Plug (Capped) 2
