Ricoh MP CW2201 Service Manual

SMC List Card Save Function
Overview
SMC List Card Save
• The SMC List Card Save (SP Text Mode) function is used to save the SMC list as CSV files to the
SD-card inserted into the operation panel SD-card slot.
Procedure
1. Turn the main power switch OFF.
2. Insert the SD card into the operation panel SD-card slot. Then turn the power ON.
3. Enter SP mode.
4. Select “Copy SP”.
5. Select SP-5992 "SP Text Mode”.
6. Select a detail SP number shown below to save data on the SD card.
SP-5992-xxx (SP Text Mode)
Detail No. SMC Categories to Save
001 All (Data List)
002 SP (Mode Data List)
003 User Program
004 Logging Data
5. System Maintenance Reference
636

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
