Ricoh MP CW2201 Service Manual

Paper Exit
• Set the main power switch to OFF and disconnect the power plug from the power outlet before the
procedure below. Operation with the power being supplied may cause electrical shock or defects.
Cutter
1. Open the front cover (p.249).
2. Left cover (p.234).
3. Raise the cutter on the right [A] of the main unit and push it to the left until it stops at [B].
4. Cutter ( x1).
4. Replacement and Adjustment
366

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
