Ricoh MP CW2201 Service Manual

Included Parts
No. Item Q'ty
1 IEEE 802.11 a/g/n Interface Unit Type M19 1
2 Hook and loop fastener Patch 2
3 Cable Sticker 8
- Caution Sheet 1
- Caution Sheet 1
Installation
• Set the main power switch to OFF and disconnect the power plug from the power outlet before
performing the procedure below. Working with power supplied may cause electrical shock or
defects.
• Do not put your hands in the controller box. It may cause trouble or injury.
• Before installing, touch the metal to eliminate static electricity. Otherwise the wireless LAN board
may be defected with static electricity
1. Remove the cover for Slot A [A] ( x2).
2. Installation
152

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
