Ink Supply

Ink Supply Unit

This section describes how to replace the ink supply unit.

Ink Supply Unit Accessories

No. Item Q'ty

1. Ink Supply Unit (ink tubes attached) 1

2. Ink Cartridges (K, C, Y, M) 4

3. Ink Sump 1

4. Ink Sump Cap 1

5. Rubber Caps 7

6. Plugs 21
