Ricoh MP CW2201 Service Manual

Scanner Unit
Original Set Sensor
• Blower brush
1. Raise the scanner unit.
2. Clean with a blower brush with the original sensor cover attached.
3. Raise the scanner unit.
4. Remove the original width sensor cover plate ( x2) (p.285).
5. Use a blower brush to clean the sensor.
Original Registration Sensor
• Blower brush
1. Raise the scanner unit.
3. Preventive Maintenance
204

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
