Auto-Nozzle Check
Auto-Nozzle Check Upper Unit
The procedure below is supposed that SP shown in the table below can be performed correctly.
SP Contents
SP2-024-001 Move the carriage.
SP2-024-002 Move the cutter.
SP2-024-003 Move the wiper of the electrode plate.
If SP shown above cannot be performed, perform the procedure in Auto-Nozzle Check Unit.
1. Move the head carriage, cutter, and wiper of the electrode plate to the specified position
with the SP2-024-001, SP2-024-002, and SP2-024-003.
2. Turn off the power.
• Before doing any procedure, always turn off the power switch and unplug the machine from
its power source. Or electric shock or defect may be caused.
3. Separate the scanner unit and main unit (p.274).
4. Open the front cover (p.249).
5. Remove the right cover (p.239)
6. Remove the right rear cover (p.247).
7. Remove the maintenance unit (p.534).
4. Replacement and Adjustment
538
To Next Page
