Ricoh MP CW2201 Service Manual

Controller Board
The controller board is located on the left in the PCB box and controls the machine. This board controls
the MFP system.
The built-in flash ROM stores various firmware for controlling the machine and security functions, such as
encryption and certification.
The printer and scanner functions can be expanded, using the optional slots (interface/SD card).
Electrical Components
889

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
