Ricoh MP CW2201 Service Manual

Scanner
Before You Begin
Safety Switch Diagram
To ensure the safety of everyone working around the machine, two switches inside the scanner section
prevent the LED radiation from switching on accidentally.
• When the original feed unit is opened and the switches open, a +24V line connecting each LED
driver on the SIF board is disconnected.
• When the original feed unit is closed and the switches close, the +24V line is re-connected.
4. Replacement and Adjustment
284

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
