Ink Supply Mechanism

No. Item

1 Ink cartridge

2 Ink supply needle

3 Cylinder

4 Plunger

5 Ink pump motor

6 Actuator

7 Ink end sensor

• When the ink cartridge (1) inserted, the ink supply needle (2) is inserted and sealed into the ink

supply port.
