Faulty Carriage Unit

• Replace the carriage unit.

Color Density Too Light

Printer Driver Settings

• Make sure the printer driver color settings are set correctly.

• Enhance the image with an image editor.

Part of Image Missing, Text Misaligned

• Image not complete

• Part of image missing

• Text misaligned
