Ricoh MP CW2201 Service Manual

7. Set the assembled stand upright.
Mounting the Scanner Unit
• Mount the main unit immediately after you have removed the box from the pallet and opened the
box.
• Do not grip the scanner unit by the front end. The front end is made of plastic only and break easily.
Parts to be Used
No. Item Q'ty
- Hex Socket Bolt*
1
4
- Lock washers 4
2. Installation
78

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
