Raising and Lowering the Print Heads
The carriage unit and print heads can be raised to two high positions (1 mm, 2 mm) to eliminate
smearing caused by the print heads rubbing across the surface of thick paper.
• The Prevent Paper Abrasion setting must be done with the User Tools menu before starting the print
job.
1. Touch User Tools icon on the machine operation panel.
2. Touch [System Settings], touch [Next], and then touch [Prevent Paper Abrasion].
3. The first selection is for a bypass print job. The second and third selections are for Roll Feed 1 and
Roll Feed 2, respectively.
4. Three selections are available for each feed location: Off (standard), Strong, and Weak.
1: Head Lift Sensor, 2: Actuator, 3: Head Lift Cam
User Tool Height Sensor
Rotate
CCW (7
sec)
Rotate CCW
(0.5 sec)
Rotate CW
(0.15 sec)
[A] Off Default ON to OFF No Yes Yes
Printing
853
