Ricoh MP CW2201 Service Manual

Main Frame Screws
There are paint-locked screws across the top of the machine (under the top cover). These screws are
positioned and adjusted at the factory. Never loosen or attempt to adjust these screws.
Right Plate Screws
You can see the heads of four paint-locked screws around the top of the maintenance unit. These screws
hold a re-enforcement plate. Never loosen or remove any of these screws.
4. Replacement and Adjustment
222

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
