Ricoh MP CW2201 Service Manual

Print Head Unit
No. Item Qty
1 Air sensors pairs 7
2 Head thermistor (Black) 1
3 Head thermistor (Color) 1
4 Purge valves 7
5 Ink sub tanks (K1, K2, Y1, M1, C, Y2, M2) 7
6 Ink sub tank feelers 7
7 Filter units 7
8 Print head units (K1, K2, Y1M1, C, Y2M2) 5
9 Print heads 5
Printing
845

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
