Ricoh MP CW2201 Service Manual

The K1 print head sits forward of the K2 print head in the direction of paper feed. This allows a greater
band of coverage during black-and-white printing. Three nozzles at the rear section of K1 and three
nozzles at the front section of K2 overlap the same area on the paper. However, the arrangement of
the nozzle ports is staggered so positions of the nozzle ports complement one another when ink is put
down on the paper.
7. Detailed Description
844

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
