Ricoh MP CW2201 Service Manual

Assembling the Scanner Stand
Accessories: Scanner Stand
No. Item Q'ty
1. Left Support 1
2. Right Support 1
3. Center Stay 2
4. Hex Socket Bolt M4x8*
1
16
4. Lock washer 16
4. Allen key 1
*1 For the scanner stand assembly and connection of scanner stand to main unit with these bolts, you
will need an Allen key. One lock washer is provided for each socket bolt.
