Ricoh MP CW2201 - Motor Timing Belt, Cutter Belt; Remove

To Next Page

To Previous Page

4. Cutter motor assembly [A] ( x2).

5. Cutter motor ( x1, gear x1, x2)

Motor Timing Belt, Cutter Belt

Remove

1. Cutter unit (p.369).

2. Cutter motor (p.374).

Paper Exit

375
