Ricoh MP CW2201 Service Manual

5. Close the front cover. Push it in and make sure that it locks.
Original Stacker, Guides
Installing the Original Stacker, Guides
1. Insert the hooks on the bottom of the original stacker [A] into the holes.
2. Push down the four tabs [B] to attach.
Main Machine Installation
115

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
