Ricoh MP CW2201 Service Manual

8. Remove the feed roller housing ( x4).
Separate the Feed Roller Housing (Roller Unit 2)
1. Remove the roll unit 2 (p.322).
2. Remove the upper part of the top cover and remove the screws on the back ( x8).
4. Replacement and Adjustment
348

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
