Common Procedures
Before You Begin
This section describes procedures commonly used to service the machine.
• The service technician must be familiar with all procedures in this section before servicing the
machine, as described in other sections of this service manual.
What You Need
Tool Needed For:
Alcohol, clean linen cloths Cleaning surfaces and rollers
Allen key (2.5 mm) Removing and attaching hex bolts.
Blower brush Cleaning sensors
Clean rags Wiping up ink, covering disconnected ink tubes
Clean waste paper To place under the maintenance unit and other parts that
can leak ink, in order to protect tables and other surfaces
Flashlight (small) Checking the position of the suction cap and print head caps
of the maintenance unit.
Gloves Handling encoder strips and wheels, and urethane-coated
rollers
Lens paper Cleaning the CIS elements
Metal scale Inserting sheets into narrow gaps.
Phillips driver – long At least 300 mm (12") to reach screws inside the machine.
Phillips driver – small Removing small screws
Radio pliers Attaching, reattaching e-rings
4. Replacement and Adjustment
228
